Thông số Mixer Yamaha MG124CX
| Outline | MG166CX | MG124CX | MG82CX | |
| Mixing capability | Mixing channels | 8 Mono + 4 Stereo | 4 Mono + 4 Stereo | 2 Mono + 3 Stereo |
| GROUP | 4 | 2 | - | |
| AUX | 3 (Incl. 1x Effect send) | 2 (Incl. 1x Effect send) | 1 (Effect send) | |
| MAIN | Stereo | Stereo | Stereo | |
| Input channel functions | CH1-6: HPF, Compressor, 3-band mid-sweep PEQ, Intert I/O; CH7-8: HPF, 3-band mid-sweep PEQ, Intert I/O; CH9-16: HPF, 3-band PEQ | CH1-4: HPF, Compressor, 3-band mid-sweep PEQ, Intert I/O; CH5-8: HPF, 3-band mid-sweep PEQ; CH9-12: HPF, 3-band PEQ | CH1-2: HPF, Compressor, 3-band PEQ, Intert I/O; CH3-6: HPF, 3-band PEQ; CH7-8: 2-band PEQ | |
| On-board processors | SPX | SPX | SPX | |
| I/O | Mic inputs | 10 | 6 | 4 |
| Phantom power | +48V DC; ON/OFF | +48V DC; ON/OFF | +48V DC; ON/OFF | |
| Line inputs | 4x Stereo, Return, 2tr in | 4x Stereo, Return, 2tr in | 3x Stereo, Return, 2tr in | |
| Control and others | Foot switch, Lamp | Foot switch | Foot switch | |
| General specifications | MG166CX | MG124CX | MG82CX | |
| Total harmonic distortion | Less than 0.1% | Less than 0.1% | Less than 0.1% | |
| Frequency response | 0, +1.0, -3dB 20Hz-20kHz | 0, +1.0, -3dB 20Hz-20kHz | 0, +1.0, -3dB 20Hz-20kHz | |
| Hum & noise level | Equivalent input noise | -128dBu | -128dBu | -128dBu |
| Residual output noise | -98dBu | -98dBu | -100dBu | |
| Crosstalk | -70dB | -70dB | -70dB | |
| Power requirements | Use PA-30 AC Adaptor (AC35VCT, 1.4A); Depend on area of purchase; AC100V, 120V or 220-240V; 50/60Hz | Use PA-20 AC Adaptor (AC35VCT, 0.94A); Depend on area of purchase; AC100V, 120V or 220-240V; 50/60Hz | Use PA-10 AC Adaptor (AC38VCT, 0.62A); Depend on area of purchase; AC100V, 120V or 220-240V; 50/60Hz | |
| Power consumption | 35W | 30W | 21W | |
| Dimensions | W | 478mm; 18-13/16in | 346.2mm; 13-5/8in | 256.6mm; 10-1/8in |
| H | 105mm; 4-1/8in | 86.1mm; 3-3/8in | 62.2mm; 2-7/16in | |
| D | 496mm; 19-1/2in (12U) | 436.6mm; 17-3/16in | 302.5mm; 11-15/16in | |
| Net weight | 5.5kg; 12.1lbs | 3.2kg; 7.1lbs | 1.6kg; 3.5lbs | |
| Accessories | Owner’s Manual, AC adaptor | Owner’s Manual, AC adaptor | Owner’s Manual, AC adaptor | |
